fitur

Spesifikasi

Toleransi dimensi: +- 2%

Tahan Angin: 3-500 km/jam

Bahan: GR50 GR65 S500 S355

Tinggi: 14m

Pengelasan: Pengelasan mengkonfirmasi dengan standar pengelasan internasional CWB

Lapisan Serbuk: Lukisan bubuk poliester murni, warna adalah opsional

Desain: terhadap gempa kelas 8

Nama Produk: Tiang Lampu Jalan yang Dapat Disesuaikan dengan Panjang hingga 14 Meter Tanpa Slip Joint dan Beberap

Informasi dasar

Tempat asal: Cina

Nama merek: Milky Way

Sertifikasi: ISO//BV

Nomor model: 14m

Syarat-syarat pembayaran & pengiriman

Kemasan rincian: Sesuai permintaan pelanggan

Waktu pengiriman: biasanya 2 minggu setelah konfirmasi

Syarat-syarat pembayaran: T/T

Menyediakan kemampuan: 300 buah tiang per hari

Galeri

Customizable Street Light Poles with Lengths up to 14 Meters Without Slip Joint and Multiple Flange Mounted or Planted Type Options

Deskripsi Produk

Product Description

9m 10m 12m Q235 Hot Dip Galvanized Street Lamp Pole With Cross Arm

Specification:

Specification:	20-50 meters street light pole
Type	street light pole
Shape	conical, hexagonal and octagonal
Material	Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52
Torlance of dimenstion	-0.02
Design Load in Kg	300~ 1000 Kg appliced to 50cm from the to pole
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Standard	Octagonal Conical tapered column Certified by SIRIM QAS INTERNATIONAL. Approved by JABATAN KERJA RAYA MALAYSIA. Conforms to Standard: Pole design : BS EN 40 Material : BS EN 10025 S275 / JIS G3101 SS400 Welding : BS 5135 Galvanizing : BS 729 / ISO 1461 ASTM A 123
Length of per section	Within 14m once forming without slip joint.
high mast pole suit for	city square,wharf,stadium
Option of high mast pole	Height from 20m to 35m Flange mounted or planted type
Production Process of high mast pole	Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration →Deburr→Galvanization or powder coating ,painting →Recalibration→Thread →Packages

Customizable Street Light Poles with Lengths up to 14 Meters Without Slip Joint and Multiple Flange Mounted or Planted Type Options 0

·Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2

(Other Material is Available on Request)

·Hot Dip Galvanized (≥86um)

·Any Color Polyester Powder Coated (≥100 um)

·Taper Conical , Octagonal, Polygon Section

·With demounted bracket design,easy loaded,install,and maintenance

·Theftproof slide lock

·Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,
