6mm Galvanized Steel Power Transmission Pole 10kV-220kV

1 pcs
MOQ
Dapat dinegosiasikan
harga
6mm Galvanized Steel Power Transmission Pole 10kV-220kV
fitur Galeri Deskripsi Produk Quote request suatu
fitur
Spesifikasi
Nama Produk: Tiang Listrik Galvanis
Membentuk: Oktagonal Atau Bulat
Kapasitas daya: 10kV hingga 220kV
Gabungan Polandia: Sendi Slip
Waktu garansi: 15 tahun
Ketebalan: 1mm sampai 36mm
Menyoroti:

6mm galvanized steel power pole

,

10kV-220kV transmission pole

,

galvanized steel transmission pole
Informasi dasar
Tempat asal: Cina
Nama merek: MilkyWay
Sertifikasi: ISO9001/BV/
Nomor model: Tiang Listrik Baja Transmisi
Syarat-syarat pembayaran & pengiriman
Kemasan rincian: sebagai permintaan pelanggan
Waktu pengiriman: 20 hari kerja setelah menerima pembayaran Anda
Syarat-syarat pembayaran: T/t, l/c saat terlihat
Menyediakan kemampuan: 300pcs per hari
Deskripsi Produk
6mm Galvanized Steel Power Transmission Poles
High-performance, long-lasting galvanized steel poles for power transmission applications from 10kV to 220kV.
Product Specifications
Attribute Value
Product Name Galvanized Power Pole
Shape Octagonal Or Round
Power Capacity 10kV to 220kV
Joint of Poles Slip joint
Warranty time 15 years
Thickness 1 mm to 36mm
Premium Steel Materials
All materials are sourced from renowned mill factories to ensure superior quality. Each shipment includes:
  • Mill certificate with official stamp and signature
  • Rigorous chemical and physical analysis before production
  • Verified strength and component specifications
6mm Galvanized Steel Power Transmission Pole 10kV-220kV 0
Detailed Specifications
Types Length 45ft (13.75m) 50ft (15.25m) 55ft (16.80m) 60ft (18.30m) 65ft (19.85m) 70ft (21.35m)
B (0°-2°) Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 345 370 395 415 435 455
Thickness (mm) 6 6 6 6 6 6
E (2°-15°) Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 545 585 625 660 700 740
Thickness (mm) 6 6 6 6 6 6
Manufacturing Tolerances
  • Component Length: -25mm to 75mm
  • Straightness: 2mm/m
  • Twisting degree: 1° per 3 meters length
  • Ovalisation: Maximum 3%
  • Average diameter: +/-0.5%
  • Slip length: +/-150mm
6mm Galvanized Steel Power Transmission Pole 10kV-220kV 1
Welding Standards
Our welding process meets the highest quality standards:
  • Internal and external double welding for superior strength
  • Certified flaw testing
  • Compliance with AWS (American Welding Society) D 1.1 standard
6mm Galvanized Steel Power Transmission Pole 10kV-220kV 2
Surface Treatment
Hot dip galvanized following ASTM A 123 standards. Custom treatments available including color polyester powder coating to meet client requirements.
Company Profile
Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China, brings over 24 years of expertise in manufacturing:
  • Transmission power poles
  • Street light poles
  • High mast poles
Our products have been exported to over 70 countries worldwide, including major projects such as:
  • Street light poles for Dubai Tower
  • High mast poles for Sochi Winter Olympic Games
6mm Galvanized Steel Power Transmission Pole 10kV-220kV 3
