Round Power pole 110KV energy High Mast Pole steel metal Material

Gambar besar : Round Power pole 110KV energy High Mast Pole steel metal Material

Detail produk:

Place of Origin:	China,Jiangsu
Nama merek:	MilkyWay
Sertifikasi:	ISO9001/BV/
Model Number:	High Mast Pole

Syarat-syarat pembayaran & pengiriman:

Minimum Order Quantity:	1 pcs
Harga:	Negotiation
Packaging Details:	As customer request
Delivery Time:	20 working days after received your payment
Payment Terms:	T/T, L/C at sight
Supply Ability:	300pcs per day

Kontak

Detil Deskripsi produk

tolerance:	+/-2%	Product Name:	Round Power pole 110KV energy High Mast Pole steel metal Material
Pole finished:	galvanized high mast pole	Payment Terms::	L/L
Supply Ability::	9000pcs per week	safty Facor:	1.8
Cahaya Tinggi:	high mast lighting pole , Sports Light Poles

Round Power pole 110KV energy High Mast Pole steel metal Material

Type	high mast pole
Shape	conical, hexagonal and octagonal
Material	Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52
Torlance of dimenstion	-0.02
Design Load in Kg	300~ 1000 Kg appliced to 50cm from the to pole
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Standard	Octagonal Conical tapered column Certified by SIRIM QAS INTERNATIONAL. Approved by JABATAN KERJA RAYA MALAYSIA. Conforms to Standard: Pole design : BS EN 40 Material : BS EN 10025 S275 / JIS G3101 SS400 Welding : BS 5135 Galvanizing : BS 729 / ISO 1461 ASTM A 123
Length of per section	Within 14m once forming without slip joint.
high mast pole suit for	city square,wharf,stadium
Option of high mast pole	Height from 20m to 35m Flange mounted or planted type
Production Process of high mast pole	Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration →Deburr→Galvanization or powder coating ,painting →Recalibration→Thread →Packages

Project:

We have completed many big and important project all over the world and win the trust of our client

Round Power pole 110KV energy High Mast Pole steel metal Material 0

To assure our products qualified ,we take steps as follows :

1. Management team : We have employ the foreign export to take chaege of the overall managemnt ,especailly the technical managemnt and quality management .

2.Introducing ISO management ,We are awared ISO 9001:2008 certificate.

3.QC Inpection:It is our company policy that all the finish product should be inspected by our specialzed QC in every manufacure steps and beofore every shipment.

Round Power pole 110KV energy High Mast Pole steel metal Material 1
